SH10T-V11
Product code 03-163Manufacturer code ASH00142
- 98,0% / 97,5%Efficiency
- 2 (2 / 1 string)MPPT channels
- 32 kgWeight
Overview
Sungrow SH10T-V11 is an inverter (98,0 / 97,5%% efficiency), for residential installs.
Specifications
General
- Category
- Inverters
- Product code
- 03-163
- Manufacturer code
- ASH00142
- Type
- 3-fase hybride omvormer
- Model
- SH10T
- Segment
- Residentieel
Power and efficiency
- Efficiency
- 98,0% / 97,5%
- Nominal AC
- 9999 W
- Recommended PV
- 20000 Wp
Electrical
- MPPT channels
- 2 (2 / 1 string)
- Battery
- Li-ion 100-700 V, max. 50 A
Mechanical
- Dimensions
- 620 x 480 x 195 mm
- Weight
- 32 kg
- IP rating
- IP65
Questions
The short ones are here. For anything else, ask below.
Sungrow SH10T-V11 is an inverter (98,0 / 97,5%% efficiency), for residential installs.
Module efficiency is 98,0 / 97,5%%.
